# | Kodas | Pastaba | Kiekis |
---|---|---|---|
(1) | 431819003K |
;;F >> 439 2109 314 |
|
heater with fresh air and heating control | ??? € | ||
(1) | 433819003 |
;;F 439 2109 315>> |
|
heater with fresh air and heating control | ??? € | ||
1 | |||
nebegaminama | ??? € | ||
1 | 431819003H |
;;F >> 439 2109 314 |
|
heater with fresh air and heating control | ??? € | ||
(1) | 431819003L |
;;F 439 2109 315>> |
|
heater with fresh air and heating control | ??? € | ||
2 | 443819030 | 1 vnt. | |
šilumokaitis | ??? € | ||
2 | 443819031 | 1 vnt. | |
šilumokaitis | ??? € | ||
2A | |||
nebegaminama | ??? € | ||
2A | 431819041 |
;F 439 2109 315>> |
|
rot. knob | ??? € | ||
3 | 431819067 | 1 vnt. | |
poveržlė ( vairas kairėje) | ??? € | ||
4 | 321819059 | 10 vnt. | |
sąvaržėlė | ??? € | ||
5 | |||
nebegaminama | ??? € | ||
5 | 431819085B |
;F >> 439 2109 314 |
|
light fibre | ??? € | ||
5A | |||
nebegaminama | ??? € | ||
5A | 433820085A |
;F 439 2109 315>> |
|
light fibre | ??? € | ||
6 | 443819095A | 1 vnt. | |
housing half (vairas kairėje) taip pat naudoti: |
;443 819 279 C | ??? € | |
- | 443819279C | 1 vnt. | |
control valve | ??? € | ||
(6) | 444819095A | 1 vnt. | |
housing half (vairas dešinėje) taip pat naudoti: |
;443 819 279 C | ??? € | |
- | 443819279C | 1 vnt. | |
control valve | ??? € | ||
- | 443819096A | 1 vnt. | |
housing half (dešinėje) | ??? € | ||
- | 431819645A | 2 vnt. | |
sąvaržėlė | ??? € | ||
7 | 443819096A | 1 vnt. | |
housing half (dešinėje) taip pat naudoti: |
;431 819 645 A | ??? € | |
8 | N 90030301 | 3 vnt. | |
oval head panel screw | 4,2X35 | ??? € | |
9 | 431819211A | 1 vnt. | |
tarpinė | ??? € | ||
10 | 431819225 | 1 vnt. | |
tarpinė | 1360MM | ??? € | |
11 | |||
nebegaminama | ??? € | ||
11 | 431819269C | 1 vnt. | |
lever for locking flap | ??? € | ||
12 | 432819269A | 1 vnt. | |
lever for locking flap | ??? € | ||
13-16 | |||
nebegaminama | ??? € | ||
13 | 431819279B | 1 vnt. | |
control valve | ??? € | ||
14 | 431819280B | 1 vnt. | |
flap for warm air cut-off | ??? € | ||
15 | 431819281B | 1 vnt. | |
footwell and defroster flap | ??? € | ||
16 | 431819291B | 1 vnt. | |
lever for fresh air | ??? € | ||
17 | 431819311 | 1 vnt. | |
guminė įvorė | ??? € | ||
18 | N 0124251 | 1 vnt. | |
užtvirtinantis žiedas | 25X1,2 | ??? € | |
19 | 431820403 | 1 vnt. | |
intake duct | ??? € | ||
(19) | 432819303B | 1 vnt. | |
intake duct | ??? € | ||
20 | N 0154381 | 4 vnt. | |
savisriegė veržlė | 3,5X16,75X11,3 | ??? € | |
21 | N 0116631 | 4 vnt. | |
poveržlė | 3,7X11X0,8 | ??? € | |
22 | N 0139587 | 4 vnt. | |
oval head panel screw | ST3,5X13-C | ??? € | |
23 | N 0139649 | 5 vnt. | |
oval head panel screw | 4,2X16 | ??? € | |
23 | N 0139644 | 5 vnt. | |
oval head panel screw | B4,2X16 | ??? € | |
24 | N 0115227 | 5 vnt. | |
poveržlė | A4,3X9X0,8 | ??? € | |
25+26 | |||
nebegaminama | ??? € | ||
25 | 431819295 | 1 vnt. | |
connecting rod | ??? € | ||
26 | 431819305 | 1 vnt. | |
šviežio oro atitvaras | ??? € | ||
27 | 431819307B | 1 vnt. | |
žarna ( vairas kairėje) | ??? € | ||
28 | 431819309B | 1 vnt. | |
atstumo detalė ( vairas kairėje) | ??? € | ||
29 | |||
nebegaminama | ??? € | ||
29 | 431819329 | 1 vnt. | |
mounting for flap | ??? € | ||
30 | 4A2819349 | 1 vnt. | |
dangtis ( vairas dešinėje) | ??? € | ||
30 | 432819349 | 1 vnt. | |
dangtis ( vairas dešinėje) | ??? € | ||
31 | |||
nebegaminama | ??? € | ||
31 | 431819333B | 1 vnt. | |
lever for air distribution | ??? € | ||
31A | 431819371E | 5D,5E,5S,;L5D,L5E,L5... | 1 vnt. |
aušinimo skysčio žarna ( vairas kairėje) (flange > heat exchanger) |
??? € | ||
(31A) | 432819371A | 5D,5E,5S,;L5D,L5E,L5... | 1 vnt. |
aušinimo skysčio žarna ( vairas dešinėje) (flange > heat exchanger) |
??? € | ||
(31A) | 432819371 | S,LS,GLS | 1 vnt. |
aušinimo skysčio žarna (flange > heat exchanger) |
??? € | ||
32 | |||
nebegaminama | ??? € | ||
32 | 431819373E | 5D,5E,5S,;L5D,L5E,L5... | 1 vnt. |
aušinimo skysčio žarna ( vairas kairėje) (flange > heater valve) |
??? € | ||
32 | 431819373E | 1 vnt. | |
aušinimo skysčio žarna (flange > heater valve) |
??? € | ||
(32) | 431819373D | S,LS,GLS | 1 vnt. |
aušinimo skysčio žarna (flange > heater valve) |
??? € | ||
33 | 431819373F | 5D,5E,5S;L5D,L5E,L5S... | 1 vnt. |
aušinimo skysčio žarna ( vairas kairėje) (heater valve > heat; exchanger) |
??? € | ||
33 | 431819373F | 1 vnt. | |
aušinimo skysčio žarna (heater valve > heat; exchanger) |
??? € | ||
(33) | 444819373C | 5D,5E,5S,;L5D,L5E,L5... | 1 vnt. |
aušinimo skysčio žarna ( vairas dešinėje) (heater valve > heat; exchanger) |
??? € | ||
(33) | 431819373C | S,LS,GLS | 1 vnt. |
aušinimo skysčio žarna ( vairas kairėje) (heater valve > heat; exchanger) |
??? € | ||
(33) | 431819373C | S,LS,GLS | 1 vnt. |
aušinimo skysčio žarna ( vairas kairėje) (heater valve > heat; exchanger) |
??? € | ||
- | 431819809A | 1 vnt. | |
šildytuvo vožtuvas žr. iliustraciją: |
;70-10 | ??? € | |
34 | N 90561801 | ||
spaustuvas | 16-28X9X0,5 | ??? € | |
35 | N 10258101 | ||
spaustuvas | 23-35X9X0,5 | ??? € | |
35 | N 0245113 | ||
spaustuvas | LC23-35 | ??? € | |
36 | 431819443 | 2 vnt. | |
spyruoklė | ??? € | ||
37 | 4D0971911 | 1 vnt. | |
guminė įvorė | 17/8,5 | ??? € | |
37 | 431819399 | 1 vnt. | |
guminė įvorė | 18/8 | ??? € | |
39 | 437919039 | 1 vnt. | |
lemputės laikiklis | ??? € | ||
40 | |||
nebegaminama | ??? € | ||
40 | 431819491A | 1 vnt. | |
vakuuminis įrenginys | ??? € | ||
41 | N 0139694 | 2 vnt. | |
oval head panel screw | ST4,8X16,0 | ??? € | |
42 | N 90015101 | 1 vnt. | |
suveržianti poveržlė | 5X11,4 | ??? € | |
43 | 321819645 | 2 vnt. | |
mounting clip | ??? € | ||
321819645 01C | |||
satino juoda | ??? € | ||
43A | 431819645 | 2 vnt. | |
sąvaržėlė | ??? € | ||
44 | 823819679 | 6 vnt. | |
sąvaržėlė | ??? € | ||
- | 431819699 | 1 vnt. | |
double grommet ( vairas kairėje) | ??? € | ||
- | 861819699A | 1 vnt. | |
double grommet ( vairas dešinėje) | ??? € | ||
45 | 4A0819849D | 2 vnt. | |
guminė įvorė | ??? € | ||
46 | |||
nebegaminama | ??? € | ||
46 | 431819823A |
;F >> 439 2109 314 |
|
rankena | ??? € | ||
431819823A 01Z | |||
tamsiai rudos spalvos (ruda) | ??? € | ||
46A | 431819823 |
;F 439 2109 315>> |
1 vnt. |
rankena | ??? € | ||
431819823 01C | |||
satino juoda | ??? € | ||
46A | 431819823 |
;F 439 2109 315>> |
1 vnt. |
rankena | ??? € | ||
431819823 01Z | |||
tamsiai rudos spalvos (ruda) | ??? € | ||
47 | |||
nebegaminama | ??? € | ||
47 | 431819837A | 1 vnt. | |
locking flap cable | 450MM | ??? € | |
48 | 431819887 | 1 vnt. | |
įtempimo dirželis | ??? € | ||
49 | 431819885 | 1 vnt. | |
įtempimo dirželis | ??? € | ||
50 | N 90030301 | 1 vnt. | |
oval head panel screw | 4,2X35 | ??? € | |
51 | |||
nebegaminama | ??? € | ||
51 | 431820043A |
;;F 439 2064 120>>;F >> 439 2109 314 |
|
gryno oro ir šildytuvo kontrolė (4 speeds) | ??? € | ||
431820043A 01Z | |||
tamsiai rudos spalvos (ruda) | ??? € | ||
(51A) | 433820043 |
;;F 439 2109 315>> |
|
fresh air and heating control with switch | ??? € | ||
(51A) | |||
nebegaminama | ??? € | ||
(51A) | 433820043 | ||
fresh air and heating control with switch | ??? € | ||
- | 433820461 | ||
switch plate with switch | ??? € | ||
- | 433820461A | ||
switch plate with 2 switches | ??? € | ||
51A | 433820043B |
;;F 439 2109 315>> |
|
gryno oro ir šildytuvo kontrolė | ??? € | ||
433820043B 01Z | |||
tamsiai rudos spalvos (ruda) | ??? € | ||
- | 431819833 | 1 vnt. | |
locking flap cable | 380MM | ??? € | |
52 | N 0139713 | 2 vnt. | |
oval head panel screw | 4,8X22 | ??? € | |
53 | N 0116653 | 2 vnt. | |
poveržlė | 5,3X15X1,6 | ??? € | |
54 | N 0154581 | 2 vnt. | |
savisriegė veržlė | 4,8X19,5X16,5 | ??? € | |
55 | |||
nebegaminama | ??? € | ||
55 | 431820625B | 2 vnt. | |
vakuuminis įrenginys | ??? € | ||
56 | 111919243 | 1 vnt. | |
lemputės laikiklis | ??? € | ||
56A | |||
nebegaminama | ??? € | ||
56A | 433959157 | 2 vnt. | |
lemputės laikiklis | ??? € | ||
57 | N 0177512 | 2 vnt. | |
lemputė | W5/1,2W12V1,2W | ??? € | |
JG 12 V 1,2 W |
|||
??? € | |||
57A | N 0177222 | 2 vnt. | |
lemputė | J-12V2W | ??? € | |
58 | 431959101C | 1 vnt. | |
fan motor with wheel ( vairas kairėje) | ??? € | ||
(58) | 444819015 | 1 vnt. | |
ventiliatoriaus variklis ( vairas dešinėje) | ??? € | ||
(59) | |||
nebegaminama | ??? € | ||
(59) | 431959127E | "S.." | 1 vnt. |
nuoseklus rezistorius | ??? € | ||
(59) | 431959127D |
;F 438 2093 886>> |
|
nuoseklus rezistorius | ??? € | ||
60 | N 0139594 | 2 vnt. | |
oval head panel screw | 3,5X16 | ??? € | |
60 | N 0139593 | 2 vnt. | |
oval head panel screw | B3,5X16 | ??? € | |
(61) | 433919577 | AUTOMATIC:;"S..","J.... | 1 vnt. |
retardation relay ( vairas kairėje) | ??? € | ||
61 | 141951253B | 1 vnt. | |
relė | ??? € | ||
61 | 431951253H | 1 vnt. | |
relė | ??? € | ||
62 | 437919039 | 1 vnt. | |
lemputės laikiklis taip pat naudoti: |
;171 971 998 A | ??? € | |
63 | N 0139755 | 2 vnt. | |
oval head panel screw | 4,8X19 | ??? € | |
63 | N 01397511 | 2 vnt. | |
oval head panel screw | B4,8X19 | ??? € | |
64 | N 0116653 | 2 vnt. | |
poveržlė | 5,3X15X1,6 | ??? € | |
65 | N 0154581 | 2 vnt. | |
savisriegė veržlė | 4,8X19,5X16,5 | ??? € | |
- | 433959621 | 1 vnt. | |
switch for air conditioner | -ON/OFF- | ??? € |
