Transporto priemonė: 450 SEL USA; VIN numerio dalis: 116033
Grupė: 50 RADIATOR
| # | Kodas | Pavadinimas |
|---|---|---|
| A 1165010301 | RADIATOR | |
| Repalced by: A 1165011501 | ||
| 001 | A 1165011501 | RADIATOR |
| A 1165012201 | RADIATOR | |
| Repalced by: A 1165012601 | ||
| 003 | A 1165012601 | RADIATOR |
| 003 | A 1165011901 | RADIATOR |
| 004 | A 1165012401 | RADIATOR |
| 005 | N 007604014106 | SCREW PLUG |
| Repalced by: N 007604014110 | ||
| 005 | N 007604014110 | SCREW PLUG |
| 007 | N 007603014405 | SEAL RING |
| 008 | A 1161801765 | OIL COOLER |
| A 1165040038 | MOUNTING PLATE | |
| 011 | A 1075040012 | RUBBER MOUNTING |
| RIGHT | ||
| 013 | A 1075040112 | RUBBER MOUNTING |
| LEFT | ||
| 014 | A 0039880678 | CLIP |
| 015 | A 0049882378 | CLIP |
| 018 | A 1165050155 | FAN SHROUD |
| A 1165050055 | FAN SHROUD | |
| Repalced by: A 1165050355 | ||
| 018 | A 1165050355 | FAN SHROUD |
| 019 | A 1165050455 | FAN SHROUD |
| 020 | A 1165050555 | FAN SHROUD |
| 021 | N 000933005031 | SCREW |
| 023 | A 0019901840 | WASHER |
| Repalced by: A 1269901440 | ||
| 023 | A 1269901440 | WASHER |
| 025 | N 912004005100 | LOCK WASHER |
| 026 | A 0005050172 | NUT |
| 028 | A 1075040186 | SPRING |
| A 1165000149 | TANK | |
| Repalced by: A 1165000249 | ||
| 031 | A 1165000249 | TANK |
| Repalced by: A 1165000449 | ||
| A 1165000249 | TANK | |
| Repalced by: A 1165000449 | ||
| A 1165000449 | TANK | |
| Repalced by: A 1265000349 | ||
| 032 | A 1265000349 | TANK |
| Repalced by: A 1265001549 | ||
| 032 | A 1265001549 | TANK |
| A 0005010044 | COVER | |
| Repalced by: A 1265000084 | ||
| A 1265000084 | COVER | |
| PARTS KIT | ||
| TO 1265001549 | ||
| A 0129970348 | SEAL RING | |
| TO 1265001549 | ||
| N 000471030002 | LOCK RING | |
| TO 1265001549 | ||
| 032B | A 0079972682 | HOSE |
| DE-AERATION | ||
| A 0005011715 | RADIATOR CAP | |
| Repalced by: A 1235010015 | ||
| A 1235010015 | RADIATOR CAP | |
| Repalced by: A 1235010115 | ||
| A 1235010115 | RADIATOR CAP | |
| Repalced by: A 1235010215 | ||
| 033 | A 1235010215 | RADIATOR CAP |
| 035 | N 007976004207 | SHEET METAL SCREW |
| 036 | N 009021005202 | WASHER |
| Repalced by: N 009021005205 | ||
| 036 | N 009021005205 | WASHER |
| 037 | A 1165013582 | HOSE |
| TOP | ||
| 038 | A 1105012282 | HOSE |
| TOP | ||
| 038E | N 916026036000 | CLAMP |
| Repalced by: A 0069970590 | ||
| 038E | A 0069970590 | LOOM TIE |
| 039 | N 916026040000 | CLAMP |
| Repalced by: A 0069974390 | ||
| 039 | A 0069974390 | LOOM TIE |
| 039B | N 916026036000 | CLAMP |
| Repalced by: A 0069970590 | ||
| 039B | A 0069970590 | LOOM TIE |
| A 1105000272 | LINE | |
| Repalced by: A 1105000472 | ||
| 040 | A 1105000472 | LINE |
| 043 | A 1105011682 | HOSE |
| 045 | A 1105011982 | HOSE |
| 048 | A 1105012582 | HOSE |
| 052 | N 916026036000 | CLAMP |
| Repalced by: A 0069970590 | ||
| 052 | A 0069970590 | LOOM TIE |
| 052 | N 916026045000 | CLAMP |
| Repalced by: A 0069970690 | ||
| 052 | A 0069970690 | LOOM TIE |
| 052 | N 916026036000 | CLAMP |
| Repalced by: A 0069970590 | ||
| 052 | A 0069970590 | LOOM TIE |
| 053 | A 0019877625 | PLASTIC SECTION |
| 50 MM | ||
| 055 | N 900271008019 | HOSE |
| Repalced by: N 000000000734 | ||
| 055 | N 000000000734 | HOSE |
| 8 X 15 X 730 MM | ||
| 057 | N 916026010000 | CLAMP |
| Repalced by: N 000000000665 | ||
| 057 | N 000000000665 | CLAMP |
| A 1079870341 | RUBBER RING | |
| Repalced by: A 1164661282 | ||
| 059 | A 1164661282 | RUBBER RING |
| N 900271018036 | HOSE | |
| Repalced by: A 1165000175 | ||
| 063 | A 1165000175 | HOSE |
| 063 | A 1165000675 | HOSE |
| A 1165000975 | HOSE | |
| 065 | A 1165000275 | HOSE |
| A 1165000875 | HOSE | |
| Repalced by: A 1165001275 | ||
| 066 | A 1165001275 | HOSE |
| 066A | A 0009955844 | CLAMP |
| 066B | A 1164660882 | RUBBER RING |
| 066C | A 1165012182 | HOSE |
| 066D | N 916026020001 | CLAMP |
| 066D | N 916026020001 | CLAMP |
| 066E | N 916026023001 | CLAMP |
| Repalced by: N 000000000667 | ||
| 066E | N 000000000667 | CLAMP |
| A 1165011482 | HOSE | |
| Repalced by: A 1165012582 | ||
| 067 | A 1165012582 | HOSE |
| TOP | ||
| 067D | A 1165012282 | HOSE |
| TOP | ||
| A 1165012782 | HOSE | |
| Repalced by: A 1165012982 | ||
| 068 | A 1165012982 | HOSE |
| 80 MM | ||
| A 1165011882 | HOSE | |
| Repalced by: A 1165012482 | ||
| 071 | A 1165012482 | HOSE |
| BOTTOM | ||
| 071F | A 1165012382 | HOSE |
| BOTTOM | ||
| 072 | A 1165013682 | HOSE |
| BOTTOM | ||
| 072B | N 916026040000 | CLAMP |
| Repalced by: A 0069974390 | ||
| 072B | A 0069974390 | LOOM TIE |
| 072D | N 916026045000 | CLAMP |
| Repalced by: A 0069970690 | ||
| 072D | A 0069970690 | LOOM TIE |
| 072E | N 916026036000 | CLAMP |
| Repalced by: A 0069970590 | ||
| 072E | A 0069970590 | LOOM TIE |
| A 1009950820 | CLAMP | |
| Repalced by: A 1239950320 | ||
| 073 | A 1239950320 | CLAMP |
| 075 | N 000933006103 | SCREW |
| Repalced by: N 304017006018 | ||
| 075 | N 304017006018 | SCREW |
| 077 | N 000934006007 | NUT |
| 079 | N 000137006204 | SPRING WASHER |
| 081 | A 0019900091 | NUT RETAINER |
| 083 | N 000933006103 | SCREW |
| Repalced by: N 304017006018 | ||
| 083 | N 304017006018 | SCREW |
| 085 | N 000137006204 | SPRING WASHER |
| 087 | A 1088350291 | CLAMP |
| 091 | A 1165010220 | BRACKET |
| Repalced by: A 1265010220 | ||
| 091 | A 1265010220 | BRACKET |
| 100 | A 0005004093 | BLOWER |
| A 0005004693 | BLOWER | |
| Repalced by: A 0005004893 | ||
| 100 | A 0005004893 | BLOWER |
| Repalced by: A 0005006093 | ||
| 100 | A 0005006093 | BLOWER |
| 100 | A 0005005093 | BLOWER |
| Repalced by: A 0005007993 | ||
| 100 | A 0005007993 | BLOWER |
| Y YYYYYYYYYYYY | PART NAME MISSING | |
| SEE FIG. NO.: | ||
| 100 | ||
| 103 | A 0005030801 | PROTECTIVE GRILL |
| 103 | A 0005031001 | PROTECTIVE GRILL |
| 103 | A 1165030001 | PROTECTIVE GRILL |
| Y YYYYYYYYYYYY | PART NAME MISSING | |
| SEE FIG. NO.: | ||
| 103 | ||
| 105 | N 000933006103 | SCREW |
| Repalced by: N 304017006018 | ||
| 105 | N 304017006018 | SCREW |
| 107 | N 000125006421 | WASHER |
| Repalced by: N 000125006449 | ||
| 107 | N 000125006449 | WASHER |
| 108 | N 912004006102 | LOCK WASHER |
