| 001 |
A 1233000204 |
ACCELERATOR PEDAL |
| 003 |
A 1233010022 |
JOINT |
| 005 |
A 1163010182 |
PAD |
|
Repalced by: A 1233000204
|
| 005 |
A 1233000204 |
ACCELERATOR PEDAL |
| 005 |
A 1163010182 |
PAD |
|
Repalced by: A 1233000204
|
| 005 |
A 1233000204 |
ACCELERATOR PEDAL |
| 008 |
A 1233010082 |
PAD |
| 009 |
A 1073010040 |
BRACKET |
|
Repalced by: A 1249888678
|
| 009 |
A 1249888678 |
CLIP |
| 015 |
A 1163000120 |
SHAFT |
| 016 |
A 1163000720 |
SHAFT |
| 018 |
A 1163010201 |
ACCELERATOR PEDAL |
| 019 |
A 1163010301 |
ACCELERATOR PEDAL |
| 021 |
A 1163010218 |
BEARING |
| 022 |
A 1153010818 |
BEARING |
| 024 |
A 1143010051 |
SPACER RING |
| 026 |
N 900055012402 |
LOCK RING |
| 028 |
N 000137008204 |
SPRING WASHER |
|
Repalced by: N 000137008212
|
| 028 |
N 000137008212 |
SPRING WASHER |
| 030 |
N 000125008418 |
WASHER |
|
Repalced by: N 000125008443
|
| 030 |
N 000125008443 |
WASHER |
| 031 |
N 000933008131 |
SCREW |
|
Repalced by: N 304017008016
|
| 031 |
N 304017008016 |
SCREW |
| 032 |
A 0029886778 |
CLIP |
| 033 |
N 000125006421 |
WASHER |
| 034 |
N 007976005205 |
SHEET METAL SCREW |
| 035 |
N 000137006204 |
SPRING WASHER |
| 036 |
N 000934006013 |
NUT |
|
Repalced by: N 304032006008
|
| 036 |
N 304032006008 |
NUT |
| 039 |
A 1093011020 |
LEVER |
| 042 |
N 000933005036 |
SCREW |
| 043 |
N 000125005317 |
WASHER |
|
Repalced by: N 000433005304
|
| 043 |
N 000433005304 |
WASHER |
| 048 |
A 1153010241 |
STOP |
| 049 |
A 1159970640 |
SEAL RING |
| 052 |
A 0003000141 |
KICK-DOWN SWITCH |
| 053 |
A 1153040151 |
NUT |
| 055 |
A 1169930610 |
SPRING |
| 057 |
A 1163000115 |
ROD |
| 059 |
N 000934005008 |
NUT |
| 061 |
A 0009911622 |
BALL SOCKET |
|
Repalced by: A 0009918922
|
| 061 |
A 0009918922 |
BALL SOCKET |
| 064 |
A 1163000128 |
LEVER |
| 066 |
A 1150720450 |
BUSHING |
| 067 |
N 006799007007 |
LOCK PLATE |
| 070 |
A 1143010097 |
BOOT |
| 070 |
A 1163010197 |
BOOT |
|
Repalced by: A 1163010297
|
| 070 |
A 1163010297 |
BOOT |
| 072 |
A 1163000036 |
BEARING BRACKET |
| 073 |
N 000933006130 |
SCREW |
| 074 |
A 1143000820 |
SHAFT |
| 075 |
A 1163001520 |
SHAFT |
| 076 |
A 1163000620 |
SHAFT |
| 076D |
A 1163001320 |
SHAFT |
| 076F |
A 1163000125 |
LEVER |
| 076K |
N 000933006103 |
SCREW |
|
Repalced by: N 304017006018
|
| 076K |
N 304017006018 |
SCREW |
| 076L |
N 000137006204 |
SPRING WASHER |
| 077 |
A 1163001120 |
SHAFT |
| 077H |
N 912007008000 |
CLIP |
|
Repalced by: N 000000002965
|
| 077H |
N 000000002965 |
SCREW |
| 077L |
A 1233010273 |
LOCK |
| 078 |
A 1263000085 |
JOINT BALL |
|
Repalced by: A 1263010485
|
|
A 1263010485 |
RUBBER BUFFER |
|
A 1163010150 |
BUSHING |
| 080 |
N 006799004001 |
LOCK PLATE |
| 081 |
A 1169935001 |
SPRING |
| 083 |
A 1093010051 |
SPACER RING |
| 086 |
A 1093000615 |
ROD |
| 086 |
A 1093000815 |
ROD |
| 090 |
A 0009911622 |
BALL SOCKET |
|
Repalced by: A 0009918922
|
| 090 |
A 0009918922 |
BALL SOCKET |
| 091 |
N 000934005013 |
NUT |
| 092 |
A 0003000015 |
ROD |
| 092 |
A 0003000115 |
ROD |
| 093 |
A 1163000215 |
ROD |
| 093 |
A 1163001015 |
ROD |
| 094 |
A 1163000815 |
ROD |
| 096 |
A 1163010097 |
DAMPING RING |
|
Repalced by: A 1163010185
|
| 096 |
A 1163010185 |
RUBBER BUFFER |
| 098 |
N 000934005008 |
NUT |
| 098B |
N 000934006013 |
NUT |
|
Repalced by: N 304032006008
|
| 098B |
N 304032006008 |
NUT |
| 098B |
N 304032006008 |
NUT |
| 098E |
N 006797006242 |
TOOTHED WASHER |
| 098E |
N 006797006242 |
TOOTHED WASHER |
| 100 |
A 0009911622 |
BALL SOCKET |
|
Repalced by: A 0009918922
|
| 100 |
A 0009918922 |
BALL SOCKET |
| 101 |
A 1163000046 |
BALL SOCKET |
| 101 |
A 1163000046 |
BALL SOCKET |
| 101D |
N 071805008300 |
SNAP RING |
| 101D |
N 071805008300 |
SNAP RING |
| 101F |
A 1169933701 |
SPRING |
| 101F |
A 1169933701 |
SPRING |
| 102 |
A 1163010050 |
BUSHING |
| 105 |
A 1169870144 |
EXPANSION PLUG |
